IMX 224MQV-W

1/3” 1.27M CMOS, 720p 120fps
DOL HDR  120dB
AEC-Q100 G2
Chroma RGGB
Temperature : -40 ~ + 105 c

欲知詳細規格請洽業務人員

ISX 016-1ACV-W

1/4” 1.26M 720P 60fps
WDR 96dB
AEC-Q100 G2
Chroma RGGB
Temperature : -40 ~ + 105 c

ISX 019-AAQV-W

1/3.8” 1.23M 720P 60fps
DOL HDR 120dB
AEC-Q100 G2
Chroma RGGB
Temperature : -40 ~ + 105 c

IMX 290NQV-W

1/2.7” 2.13M 1080P 120fps
DOL HDR  120dB
AEC-Q100 G2
Chroma RGGB
Temperature : -40 ~ + 105 c

IMX 390CQV-W

1/2.7” 2.45M 1080P 60fps
DOL HDR  120dB
LED Flicker Mitigation
AEC-Q100 G2
ASIL C
Chroma RGGB
Temperature : -40 ~ + 105 c

IMX 490AALG-W

1/1.55” 5.4M  Full pixel 40fps
DOL WDR 120dB
LED Flicker Mitigation
AEC-Q100 G2
ASIL D
Chroma RGGB
Temperature : -40 ~ + 105 c

IMX 324AAGG-W

1/1.7” 7.42M  Full pixel 40fps
DOL WDR 120dB
AEC-Q100 G2
ASIL B
Chroma RCCC
Temperature : -40 ~ + 105 c

IMX 424AAGP-W

1/1.7” 7.42M  Full pixel 40fps
DOL WDR 120dB
AEC-Q100 G2
ASIL B
Chroma RCCB
Temperature : -40 ~ + 105 c

ISX 020-AAQV-W

1/3.75” 1.23M 720P YUV 60fps
DOL HDR 120dB
AEC-Q100 G2
Chroma RGGB
Temperature : -40 ~ + 105 c

ISX 021-AAQV-W

1/ 2.6” 2.5M 1080P YUV 60fps
DOL HDR 120dB
AEC-Q100 G2
ASIL B
Chroma RGGB
Temperature : -40 ~ + 105 c

ISX 031-AAQV-W

1/ 2.3” 3M YUV 60fps
DOL HDR 120dB
AEC-Q100 G2
ASIL B
Chroma RGGB
Temperature : -40 ~ + 105 c

IMX 623-AAQV-W

1/ 2.3” 3M 60fps
DOL HDR 120dB
AEC-Q100 G2
ASIL B
Chroma RGGB
Temperature : -40 ~ + 105 c

IMX 728-AAQV-W

1/1.7” 8.29M  40fps
DOL WDR 130dB
AEC-Q100 G2
ASIL B
Chroma RGGB
Temperature : -40 ~ + 105 c
