ST-293 5MP IP Camera module Series

ST-293 5MP IP Camera module Series

．1./2.8" Sony Sensor
．1920P real-time, high-definition, high-resolution video
．H.265 video compression
．Support for plug-in PoE module
．Dual board modular design
．Suitable for security surveillance applications
．Integrated IVA image recognition (Tamper detection, ROI detection, Tripwire detection, Object tracking)

Overview
Specification
Dimensions

The module features the Sony IMX335 CMOS image sensor for outstanding image quality and low noise. Augentix’s proprietary Optical Flow technology is incorporated to provide a total solution for the development of smart Network Camera solutions.

Model	ST-293
Image Unit	HC1783S ; 1/2.8" Sony IMX335 CMOS
Minimum illumination	Color 0.5Lux@F2.0 ; B/W 0.1Lux@F2.0
Signal-to-Noise Ratio	≧50db(AGC off)
Wide Dynamic Range	>80db
Flash storage	128MB
Memory	4Gb
Onvif Support	Yes
Browser	IE/Firefox/Chrome/Safari
CGI	Support
Mobile Phone Support	Support for browsing and configuration over mobile phone
Auto IRIS	X
Local storage	X
Smart recognition	Tamper detection, ROI detection, Line Crossing detection, Object detection
Audio input	1CH MIC In/ Line In pin
Audio output	Audio output port
CVBS output	X
Storage interface	X
I/O Interface	X
I/O function	IR filter 1, IR light 1
Internet	10/100 Mbps
Image Compression Format	H.265 / H.264 / MJPEG
Image Resolution	Mainstream: 25921944, 19201080 Sub-stream: 1280720, 640480
Transmission	64-4096Kbps, Support CBR-VBR
Operating Temperature/ Storage Temperature	-10°~50° / -20°~60°
Operating Humidity/ Storage Humidity	80%RH / 90%RH
Power Supply	DC12V / PoE Option
Power Consumption	3W(Max)
Dimensions	38(L)*38(W)mm

‧Specifications are subject to change without notice.
